[ Huaqiang Security Network News ] Integrated camera refers to the integration of the camera and lens into a single body, which can easily control the lens (multiple, focus, aperture). The main indicators of the integrated camera are as follows:
First, the resolution <br> The resolution of the camera is determined by the number of pixels of the CCD. At present, the color integrated camera is divided into two types: high line (480 TV line) and low line (420 TV line), because of the cooperation of the lens aperture, Both use a 1/4" CCD, the high line usually uses SONY's ICX229AK, the low line usually uses SONY's ICX227AK, and the high line low illumination usually uses SONY's EXVIEWCCDICX279AK.
Second, optical zoom <br> Optical zoom multiple is an important indicator to measure the space imaging range of integrated cameras, currently 16 times, 22 times, 27 times, etc., plus electronic amplification, can clearly monitor the target of 300 meters .
Third, the minimum illumination <br> Generally , the minimum illumination of the color CCD integrated camera is determined by the sensitivity of the CCD. At present, the 1/4′′ color CCD adopts the SONY ICX279AKEXVIEW CCD, which has a very low illumination. Lower illumination, but after applying this technique, the frame rate is too slow, reaching about 1 frame/second, and the image jumps and the target of moving will be severely tailed.
Fourth, other common performance
1, electronic amplification: generally 10 times.
2. Communication port: RS232C/RS422
3, auto focus: can be converted with manual focus.
4, white balance: often have automatic white balance, manual white balance and factory-set multiple specific color temperature (from 2900K to 9600K) mode.
5. S terminal output.
6, automatic aperture.
Second, optical zoom <br> Optical zoom multiple is an important indicator to measure the space imaging range of integrated cameras, currently 16 times, 22 times, 27 times, etc., plus electronic amplification, can clearly monitor the target of 300 meters .
Third, the minimum illumination <br> Generally , the minimum illumination of the color CCD integrated camera is determined by the sensitivity of the CCD. At present, the 1/4′′ color CCD adopts the SONY ICX279AKEXVIEW CCD, which has a very low illumination. Lower illumination, but after applying this technique, the frame rate is too slow, reaching about 1 frame/second, and the image jumps and the target of moving will be severely tailed.
Fourth, other common performance
1, electronic amplification: generally 10 times.
2. Communication port: RS232C/RS422
3, auto focus: can be converted with manual focus.
4, white balance: often have automatic white balance, manual white balance and factory-set multiple specific color temperature (from 2900K to 9600K) mode.
5. S terminal output.
6, automatic aperture.
